Littelfuse Inc. HE751A1210
- HE751A1210
- Littelfuse Inc.
- RELAY REED SPST 500MA 12V
- Signal Relays, Up to 2 Amps
- HE751A1210 Hoja de datos
- -
- -
- Lead free / RoHS Compliant
- 2005
- Inventario al contado / distribuidor autorizado / inventario restante de la fábrica
- Garantía de calidad de 1 año 》
- Haga clic para obtener tarifas
Part Number HE751A1210 |
Category Signal Relays, Up to 2 Amps |
Manufacturer Littelfuse Inc. |
Description RELAY REED SPST 500MA 12V |
Package - |
Series HE700 |
Features Diode |
Operating Temperature -20°C ~ 85°C |
Mounting Type Through Hole |
Termination Style PC Pin |
Contact Form SPST-NO (1 Form A) |
Operate Time 1ms |
Release Time 1ms |
Coil Type Non Latching |
Coil Current 12mA |
Coil Voltage 12VDC |
Contact Rating (Current) 500mA |
Switching Voltage 300VDC - Max |
Turn On Voltage (Max) 8 VDC |
Turn Off Voltage (Min) 1 VDC |
Package_case - |
